Predicted line from linear model fit — stat_poly

stat_poly_line() fits a polynomial, by default with stats::lm(), but alternatively using robust regression or generalized least squares. Predicted values and a confidence band, if possible, are computed and, by default, plotted.

Usage

stat_poly_line(
  mapping = NULL,
  data = NULL,
  geom = "smooth",
  position = "identity",
  ...,
  orientation = NA,
  method = "lm",
  formula = NULL,
  se = NULL,
  fit.seed = NA,
  fm.values = FALSE,
  n = 80,
  fullrange = FALSE,
  level = 0.95,
  method.args = list(),
  n.min = 2L,
  na.rm = FALSE,
  show.legend = NA,
  inherit.aes = TRUE
)

Arguments

mapping: The aesthetic mapping, usually constructed with aes. Only needs to be set at the layer level if you are overriding the plot defaults.
data: A layer specific dataset, only needed if you want to override the plot defaults.
geom: The geometric object to use display the data
position: The position adjustment to use for overlapping points on this layer.
...: other arguments passed on to layer. This can include aesthetics whose values you want to set, not map. See layer for more details.
orientation: character Either "x" or "y" controlling the default for formula. The letter indicates the aesthetic considered the explanatory variable in the model fit.
method: function or character If character, "lm", "rlm", "lts". "gls" "ma", "sma", or the name of a model fit function are accepted, possibly followed by the fit function's method argument separated by a colon (e.g. "rlm:M"). If a function is different to lm(), rlm(), ltsReg(), gls(), ma, sma, it must have formal parameters named formula, data, weights, and method. See Details.
formula: a formula object. Using aesthetic names x and y instead of original variable names.
se: Display confidence interval around smooth? (`TRUE` by default only for fits with lm() and rlm(), see `level` to control.)
fit.seed: RNG seed argument passed to set.seed(). Defaults to NA, indicating that set.seed() should not be called.
fm.values: logical Add metadata and parameter estimates extracted from the fitted model object; FALSE by default.
n: Number of points at which to predict with the fitted model.
fullrange: Should the fit span the full range of the plot, or just the range of the data group used in each fit?
level: Level of confidence interval to use (0.95 by default).
method.args: named list with additional arguments. Not data or weights which are always passed through aesthetic mappings.
n.min: integer Minimum number of distinct values in the explanatory variable (on the rhs of formula) for fitting to the attempted.
na.rm: a logical indicating whether NA values should be stripped before the computation proceeds.
show.legend: logical. Should this layer be included in the legends? NA, the default, includes if any aesthetics are mapped. FALSE never includes, and TRUE always includes.
inherit.aes: If FALSE, overrides the default aesthetics, rather than combining with them. This is most useful for helper functions that define both data and aesthetics and shouldn't inherit behaviour from the default plot specification, e.g. borders.

Value

The value returned by the statistic is a data frame, with n rows of predicted values and their confidence limits. Optionally it will also include additional values related to the model fit. When a predict() method is not available for the fitted model class, the value returned by calling fitted(), if available, is returned instead, with a message. In case of failure data.frame(), an empty data frame, is returned resulting without issuing an error, in plot layer addition being skipped, for the failing data group.

Details

This statistic is similar to stat_smooth() but has different defaults and supports additional model fit functions. It also interprets the argument passed to formula differently than stat_smooth(), accepting y as explanatory variable and setting orientation automatically. The default for method is "lm" and spline-based smoothers like loess are not supported.

Other defaults are consistent with those in stat_poly_eq(), stat_quant_line(), stat_quant_band(), stat_quant_eq(), stat_ma_line(), stat_ma_eq(). As some model fitting functions can depend on the RNG (pseudo-Random Number Generator), fit.seed if not NA is used as argument in a call to set.seed() immediately ahead of model fitting.

geom_poly_line() treats the x and y aesthetics differently and can thus has two orientations. The orientation can be deduced from the argument passed to formula. Thus, stat_poly_line() will by default guess which orientation the layer should have. If no argument is passed to formula, the formula defaults to y ~ x. For consistency with stat_smooth orientation can be also specified directly passing an argument to the orientation parameter, which can be either "x" or "y". The value of orientation gives the aesthetic that is taken as the explanatory variable in the model formula.

A ggplot statistic receives as data a data frame that is not the one passed as argument by the user, but instead a data frame with the variables mapped to aesthetics. In stat_poly_eq() the compute function is applied by group, each call "seeing" the subset of data for an individual group. As supported models are for regression lines, variables mapped to x and y should both be continuous, i.e., numeric or date time and model formulas defined using x and y as variable names.

With method "lm", singularity results in terms being dropped with a message if more numerous than can be fitted with a singular (exact) fit. In this case and if the model results in a perfect fit due to low number of observation, estimates for various parameters are NaN or NA.

With methods other than "lm", the model fit functions simply fail in case of singularity, e.g., singular fits are not implemented in "rlm".

In both cases the minimum number of observations with distinct values in the explanatory variable can be set through parameter n.min. The default n.min = 2L is the smallest suitable for method "lm" but too small for method "rlm" for which n.min = 3L is needed. Anyway, model fits with very few observations are of little interest and using larger values of n.min than the default is wise.

Note

Currently confidence bands for the regression line are not plotted in some cases, and in the case of MA and SMA models, the band only displays the uncertainty of the slope rather than for both slope plus intercept.

Model fit methods supported

Several model fit functions are supported explicitly (see tables), and some of their differences smoothed out. Compatibility is checked late, based on the class of the returned fitted model object. This makes it possible to use wrapper functions that do model selection or other adjustments to the fit procedure on a per panel or per group basis. Moreover, if the value returned as model fit object is NULL no layer is added to the plot on a per group within panel basis.

In the case of fitted model objects of classes not explicitly supported an attempt is made to find the usual accessors and/or fitted object members, and if found, either complete or partial support is frequently achieved. In this case a message is issued encouraging users to check the valisdity of the values extracted.

The argument to parameter method can be either the name of a function object, possibly using double colon notation, or a character string matching the function name. This approach makes it possible to support model fit functions that are not dependencies of 'ggpmisc'. Either by attaching the package where the function is defined and passing it by name or as string, or using double colon notation when passing the name of the function. User-defined functions can be passed as argument to parameter method as long as they have parameters formula, data subset and possibly weights. Additional arguments can be passed to any method as a named list as an argument to parameter method.args. As in stat_smooth() prior weights are passed to the model fit functions' weights (plural!) parameter by mapping a numeric variable to plot aesthetic weight (singular!).

The table below lists natively supported model fit functions, with the caveat that only some 'broom' methods' specializations have been actually tested with statistics from 'ggpmisc'. In addition, the statistics based on 'broom' methods require the user to tailor their behaviour by passing additional arguments in the call.

Statistic	\(f\)	Supported model fit methods
`stat_poly_line()`	G	"lm", "rlm", "lts", "sma", "ma", "gls", others with methods `predict()` or `fitted()`
`stat_poly_eq()`	G	"lm", "rlm", "lts", "sma", "ma", "gls", others with needed accesors
`stat_quant_line()`	G	"rq", "rqss"
`stat_quant_band()`	G	"rq", "rqss"
`stat_quant_eq()`	G	"rq", "rqss"
`stat_ma_line()`	G	"SMA", "MA", "RMA", "OLS"
`stat_ma_eq()`	G	"SMA", "MA", "RMA", "OLS"
`stat_fit_residuals()`	G	"lm", "rlm", "lts", "sma", "ma", "gls", "rq", "rqss" others with method `residuals()`
`stat_fit_fitted()`	G	"lm", "rlm", "lts", "gls", "rq", "rqss" others with method `fitted()`
`stat_fit_deviations()`	G	"lm", "rlm", "lts", "gls", "rq", "rqss" others with methods `fitted()` and `weights()`
`stat_fit_augment()`	G	any with 'broom' method `augment()`
`stat_fit_glance()`	G	any with 'broom' method `glance()`
`stat_fit_tidy()`	G	any with 'broom' method `tidy()`
`stat_fit_tb()`	P	any with 'broom' method `tidy()`

The table below lists the names for fit methods coded in the statistics as given in the table above. The single colon notation is based on parsing the name and is available whenever passing the name of the fit method as a character string. In a string such as "head:tail" the "head" gives the name of the model fit function and the "tail" gives the argument to pass it's method parameter. In some cases the default formula = y ~ x needs to be overridden with an explicit argument.

Predefined method names	Model fit methods	R package	Object class
"lm", "lm:qr"	`lm()`	'stats'	"lm"
"rlm", "rlm:M", "rlm:MM"	`rlm()`	'MASS'	"rlm" ("lm")
"lts", "ltsReg"	`ltsReg()`	'robustbase'	"lts"
"ma", "sma", "sma:SMA", "sma:MA", "sma:OLS"	`sma()`	'smatr'	"ma" or "sma"
"gls", "gls:REML", "gls:ML"	`gls()`	'nlme'	"gls"
"rq", "rq:sfn", "rq:sfnc", "rq:lasso"	`rq()`	'quantreg'	"rq"
"rqss", "rqss:sfn", "rqss:sfnc", "rqss:lasso"	`rqss()`	'quantreg'	"rqss"
"SMA", "MA", "RMA", "OLS"	`lmodel2()`	'lmodel2'

Computed variables

`stat_poly_line()` provides the following variables, some of which depend on the orientation:

y or x: predicted value
ymin or xmin: lower confidence limit around the fitted line
ymax or xmax: upper confidence limit around the fitted line
se: standard error

If fm.values = TRUE is passed then columns based on the summary of the model fit are added, with the same value in each row within a group. This is wasteful and disabled by default, but provides a simple and robust approach to achieve effects like colouring or hiding of the model fit line based on P-values, r-squared, adjusted r-squared or the number of observations.

Aesthetics

stat_poly_line() understands the following aesthetics. Required aesthetics are displayed in bold and defaults are displayed for optional aesthetics:

•	`x`
•	`y`
•	`group`	→ inferred

Learn more about setting these aesthetics in vignette("ggplot2-specs").

Examples

ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line()


# same as default
ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line(formula = y ~ x)


ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line(formula = x ~ y)


ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line(formula = y ~ poly(x, 3))


ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line(formula = x ~ poly(y, 3))


# Smooths are automatically fit to each group (defined by categorical
# aesthetics or the group aesthetic) and for each facet.

ggplot(mpg, aes(displ, hwy, colour = class)) +
  geom_point() +
  stat_poly_line(se = FALSE)


ggplot(mpg, aes(displ, hwy)) +
  geom_point() +
  stat_poly_line() +
  facet_wrap(~drv)


# Inspecting the returned data using geom_debug_group()
gginnards.installed <- requireNamespace("gginnards", quietly = TRUE)

if (gginnards.installed)
  library(gginnards)

if (gginnards.installed)
  ggplot(mpg, aes(displ, hwy)) +
    stat_poly_line(geom = "debug_group")

#> [1] "PANEL 1; group(s) -1; 'draw_function()' input 'data' (head):"
#>          x        y     ymin     ymax flipped_aes PANEL group orientation
#> 1 1.600000 30.04871 29.17768 30.91974       FALSE     1    -1           x
#> 2 1.668354 29.80738 28.95779 30.65696       FALSE     1    -1           x
#> 3 1.736709 29.56605 28.73763 30.39446       FALSE     1    -1           x
#> 4 1.805063 29.32471 28.51718 30.13225       FALSE     1    -1           x
#> 5 1.873418 29.08338 28.29640 29.87036       FALSE     1    -1           x
#> 6 1.941772 28.84205 28.07529 29.60882       FALSE     1    -1           x

if (gginnards.installed)
  ggplot(mpg, aes(displ, hwy)) +
    stat_poly_line(geom = "debug_group", fm.values = TRUE)

#> [1] "PANEL 1; group(s) -1; 'draw_function()' input 'data' (head):"
#>          x        y     ymin     ymax      p.value r.squared adj.r.squared   n
#> 1 1.600000 30.04871 29.17768 30.91974 2.038974e-46 0.5867867     0.5850056 234
#> 2 1.668354 29.80738 28.95779 30.65696 2.038974e-46 0.5867867     0.5850056 234
#> 3 1.736709 29.56605 28.73763 30.39446 2.038974e-46 0.5867867     0.5850056 234
#> 4 1.805063 29.32471 28.51718 30.13225 2.038974e-46 0.5867867     0.5850056 234
#> 5 1.873418 29.08338 28.29640 29.87036 2.038974e-46 0.5867867     0.5850056 234
#> 6 1.941772 28.84205 28.07529 29.60882 2.038974e-46 0.5867867     0.5850056 234
#>   fm.class fm.method fm.formula fm.formula.chr flipped_aes PANEL group
#> 1       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#> 2       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#> 3       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#> 4       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#> 5       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#> 6       lm     lm:qr      y ~ x          y ~ x       FALSE     1    -1
#>   orientation
#> 1           x
#> 2           x
#> 3           x
#> 4           x
#> 5           x
#> 6           x

if (gginnards.installed)
  ggplot(mpg, aes(displ, hwy)) +
    stat_poly_line(geom = "debug_group", method = lm, fm.values = TRUE)

#> [1] "PANEL 1; group(s) -1; 'draw_function()' input 'data' (head):"
#>          x        y     ymin     ymax      p.value r.squared adj.r.squared   n
#> 1 1.600000 30.04871 29.17768 30.91974 2.038974e-46 0.5867867     0.5850056 234
#> 2 1.668354 29.80738 28.95779 30.65696 2.038974e-46 0.5867867     0.5850056 234
#> 3 1.736709 29.56605 28.73763 30.39446 2.038974e-46 0.5867867     0.5850056 234
#> 4 1.805063 29.32471 28.51718 30.13225 2.038974e-46 0.5867867     0.5850056 234
#> 5 1.873418 29.08338 28.29640 29.87036 2.038974e-46 0.5867867     0.5850056 234
#> 6 1.941772 28.84205 28.07529 29.60882 2.038974e-46 0.5867867     0.5850056 234
#>   fm.class fm.method fm.formula fm.formula.chr flipped_aes PANEL group
#> 1       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#> 2       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#> 3       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#> 4       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#> 5       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#> 6       lm        lm      y ~ x          y ~ x       FALSE     1    -1
#>   orientation
#> 1           x
#> 2           x
#> 3           x
#> 4           x
#> 5           x
#> 6           x
